Auto & Transportation
Auto & Transportation Parts: Brake Rotors, Brackets, Busbars & Plates
Accubeam precision grinds high-performance brake rotors, resurfaces brake discs for light rail and monorail systems, and makes brackets, skid plates, busbars, panels and certification plates for cars, trucks, buses, trailers and specialty vehicles. Laser cut, formed, ground, machined and marked in one Sarasota shop, from one prototype to production runs.
6kW Fiber
Steel, stainless & aluminum to 1″
100-Ton
TRUMPF press brake, 120″
Brake Rotors
Ground flat & parallel
AS9100D
& ISO 9001:2015 · NSF-ISR
Since 1999
Made in Sarasota, FL
Fast
Quoting & turnaround
What vehicle builders and fleets need from a parts supplier
Performance brands, race teams, vehicle builders and transit fleets need parts that are flat, true and on time, from a shop that can turn a drawing or a worn part into finished parts quickly, without tooling or minimums.
From CAD to parts, fast
Send a DXF or STEP and get cut, formed parts back quickly. No dies, no tooling charges, and the next revision is just a new file.
Cut and bent right the first time
Flat patterns developed for our TRUMPF press brake, with bend deductions and hole locations checked before the run, so brackets bolt up.
Rotors that run true
Brake rotors ground flat and parallel, with thickness variation and runout held tight, so brakes don’t pulse and pads bed in evenly.
Marks that survive heat and grime
Part numbers, logos and data matrix codes laser-marked into the part, so they last through powder coat, heat cycles and under-hood fluids.
Fleet parts back in service
Transit and rail brake discs resurfaced and checked against their wear limits, so fleets keep rotors in service longer instead of replacing them.
A real quality system
AS9100D and ISO 9001:2015 certified, with first article inspection, material certs and the documentation tier suppliers ask for.
Auto & transportation capabilities
Brake rotors ground, cut and resurfaced; fabricated parts and busbars for vehicles; the plates and panels that identify and control them; and the fixtures used to build them.
Brake rotors
Performance
Precision Ground Performance Rotors
High-performance and racing brake rotors ground to tight flatness, parallelism and thickness.
- Blanchard ground on a 60″ table, rotors up to 60″ diameter
- Alloy steel, cast iron and any other rotor metal
- Thickness variation (DTV) and runout held to your spec
- Drilled, slotted and two-piece rotors
- Warped rotors straightened and shimmed before grinding
- Production runs for rotor brands
Made to print
Laser Cut & Ground Rotors
Rotors made from plate when you need a custom or low-volume design.
- Cut on the 6kW fiber laser from alloy steel or stainless plate
- Drill patterns, slots and lightening cut in the same pass
- Ground flat and to thickness after cutting
- Prototypes, race, kart, motorcycle and specialty rotors
- Part numbers marked on every rotor
Transit
Light Rail, Monorail & Bus Rotor Resurfacing
Brake discs from transit vehicles resurfaced and returned to service.
- Light rail, monorail and people-mover brake discs
- Bus and heavy-truck air disc brake rotors
- Faces Blanchard ground flat and parallel, up to 60″ diameter
- Straightened and shimmed first, so only the material needed comes off
- Thickness checked against the discard limit
- Measurement report with each set
Brackets & fabricated parts
Brackets
Brackets, Mounts & Gussets
Engine, suspension, body and accessory brackets for cars, trucks, buses and trailers.
- Steel, stainless and aluminum to 1″
- Formed on a 100-ton, 120″ press brake
- Tab-and-slot parts for fast welding fit-up
- Threaded holes machined on a HAAS VF3
- Part numbers and logos marked
Protection
Skid Plates, Guards & Armor
Underbody protection and guards for off-road, work and specialty vehicles.
- 5052 aluminum and steel skid plates
- AR400 and AR500 plate for heavy-duty guards
- Formed edges and flanges
- Lightening holes and mounting slots
Heat & panels
Heat Shields & Panels
Thin-gauge parts for engine bays, cabs and interiors.
- Stainless and aluminum heat shields, plain or perforated
- Firewall, floor and block-off plates
- Bus and truck interior and access panels
- Step plates and trim panels
EV & electrical
Busbars
Busbars & Power Connectors
Copper and aluminum busbars for EV, hybrid, bus and specialty vehicle power systems.
- Copper and aluminum, cut on the fiber laser
- Formed on the press brake
- Plating and insulation through outside finishers
- Part numbers and polarity marked
Batteries
Battery Trays, Boxes & Hold-Downs
Sheet metal for battery packs and auxiliary power systems.
- Aluminum and steel trays and enclosures
- Hold-downs and mounting brackets
- Threaded inserts installed
- Insulators cut from Kapton® and other films
Charging
Charger & Electrical Enclosures
Enclosures, panels and plates for charging and onboard electrical equipment.
- Enclosures and mounting plates
- Engraved panels and rating plates
- Gaskets for weather sealing
- Serialized labels
Identification & control
Certification
Certification & Tire Information Plates
Plates for trailer, body and specialty vehicle builders.
- Certification labels per your 49 CFR 567 wording
- GVWR, GAWR, tire and rim data
- Stainless and anodized aluminum
- Serialized from your production list
Panels
Switch, Dash & Control Panels
Engraved panels for race cars, off-road builds, work trucks, buses and emergency vehicles.
- Black and clear anodized aluminum, engraved plastics
- Cutouts for toggles, rockers, gauges and breakers
- Back-lit legends: paint laser-removed so the legend lights
- Matched panels for each vehicle model
Traceability
Part Marking & Traceability
Permanent identification on components for production and warranty tracking.
- Data matrix, serial and lot codes on parts
- Deep marks that read through coating
- Rotary marking on shafts and round parts
- Codes graded and verified
- Logos and branding on billet and anodized parts
Tooling & fixtures
Fixtures
Weld & Check Fixture Plates
Fixture bases ground flat for production and prototype builds.
- Blanchard ground, flat and parallel
- Locating and dowel holes machined
- Laser-cut fixture details and nests
- Marked with fixture and part numbers
Gauges
Gauges & Templates
Flat gauges and templates for the line and the shop.
- Go/no-go and profile gauges
- Drill and layout templates
- Ground to ±0.001″ where it counts
- Engraved scales and IDs
Shims
Shims, Spacers & Gaskets
Small parts that keep assemblies aligned and sealed.
- Precision shims and spacers
- Stainless, steel, brass and aluminum
- Gaskets in rubber, cork and gasket papers
- Cut from CAD, no die charges
One shop, start to finish: laser cut (TRUMPF TruLaser 1030 6kW fiber, 5′ × 10′) → formed (TRUMPF TruBend 2100, 100 tons) → ground & machined (Blanchard, surface, HAAS VF3) → marked → finished: tumbled, sanded or blasted in-house, with powder coat, anodize and plating through outside finishers.
Typical auto & transportation parts we produce
A sample of recurring work for performance brands, race teams, vehicle builders, transit operators and suppliers. We don’t publish customer names.
| Part | Materials | Processes |
|---|---|---|
| High-performance and racing brake rotors | Alloy steel, cast iron, other metals | Straightening, shimming, Blanchard grinding |
| Laser-cut custom rotors | Alloy steel, stainless | Fiber laser cutting, grinding, marking |
| Light rail, monorail and bus brake discs | Alloy steel, cast iron | Straightening, Blanchard resurfacing, thickness inspection |
| Busbars and power connectors | Copper, aluminum | Fiber laser cutting, forming, marking |
| Engine, transmission and accessory brackets | Steel, stainless, aluminum | Fiber laser cutting, press brake forming, machining |
| Suspension and chassis gussets and tabs | Steel, alloy steel | Fiber laser cutting, forming |
| Skid plates and guards | 5052 aluminum, steel, AR400/AR500 | Laser cutting, forming, marking |
| Heat shields | Stainless, aluminum | Laser cutting, forming |
| Battery trays, boxes and hold-downs | Aluminum, steel | Laser cutting, forming, inserts |
| Certification and tire information plates | Stainless, anodized aluminum | Laser marking, serialization |
| Switch, dash and control panels | Anodized aluminum, plastics | Cutting, engraving |
| Serialized components | Steel, aluminum, stainless | Data matrix marking, rotary marking |
| Billet and anodized branded parts | Anodized aluminum | Laser engraving |
| Weld and check fixture plates | Steel, aluminum | Laser cutting, Blanchard grinding, machining |
| Shims, spacers and gaskets | Steel, stainless, brass; rubber, cork | Fiber and CO2 laser cutting, grinding |
Laser cut rotor
Light rail & monorail
Race car switch panel
Trailer certification plate
Quality and documentation
Auto and transportation work runs under the same AS9100D and ISO 9001:2015 quality system we use for aerospace, certified by NSF-ISR.
- First article inspection before production
- Material certs with heat traceability
- Certificate of Conformance with every shipment
- Dimensional inspection with Keyence image measurement and CMM
- Data matrix grade verification with scan reports
- PPAP documentation on request
How an order works
1
Send the files
DXF or STEP, material and thickness, finish, and quantity. A sketch or a sample part works too.
2
Quick quote
We quote fast and flag bend radii, hole-to-bend distances or features that would cause trouble.
3
Prototype
Prototype parts for test fit on the vehicle. Adjust the file and we’ll cut the next revision.
4
Production
Production runs, marked and finished, shipped on your schedule or stocked for repeat orders.
Auto & transportation FAQ
Can you grind high-performance brake rotors?
Yes. We Blanchard grind rotors on a 60″ table, so rotors up to 60″ in diameter fit. Most are alloy steel, but we can grind any metal. Warped rotors are straightened and shimmed before grinding, and we hold thickness, flatness, thickness variation and runout to your spec.
Can you make a rotor from scratch?
Yes. For custom and low-volume designs we laser cut rotors from alloy steel or stainless plate, with drill and slot patterns, then grind them flat and to thickness and mark them.
Do you resurface transit and rail brake discs?
Yes. We resurface brake discs from light rail, monorail and people-mover systems, plus bus and heavy-truck rotors, checking each against its discard thickness and sending a measurement report with each set.
Can you make just one prototype?
Yes. There’s no minimum and no tooling, so a single test-fit bracket is as easy as a production run. We offer fast quoting and fast turnaround.
Do you weld?
No. We cut, form, machine and mark parts, and design-friendly features like tabs and slots make them fast for you or your welder to assemble.
Can you make trailer certification plates?
Yes. We laser-mark certification and tire information plates in stainless or anodized aluminum from the data and wording you provide under 49 CFR 567, serialized for each unit. Your compliance team owns the content; we make the plate.
Do you make VIN plates?
We make plates for manufacturers as part of their production process. We don’t make replacement VIN plates for individual vehicles.
Are you IATF 16949 certified?
No. We’re certified to AS9100D and ISO 9001:2015. Many automotive and transportation customers accept ISO 9001 suppliers, especially for prototypes, aftermarket and specialty-vehicle work; check your customer-specific requirements.
Can marks survive powder coating?
Yes. We can mark deeper so codes read through coating, mask the mark area, or mark after finishing, depending on the part and the code.
